Frequently Asked Questions
What is the processing range of the tube extrusion line?
Depending on the model selection, the processing range for tube production spans from a minimum diameter of 4.0 mm up to a maximum of 40.0 mm. For smaller diameters (4.0-10.0 mm), the SXG-45x25 model is recommended, while the SXG-90x45 model handles larger tubes up to 40.0 mm.
What is the L/D ratio of these extrusion machines?
All models in the SXG series feature an L/D (Length/Diameter) ratio of 28-30, ensuring excellent melt quality and optimal material homogenization.
How does the main motor power scale across different models?
The main motor power scales according to machine capacity: 11 kW for the SXG-45x25 model, 18.5 kW for SXG-50x30, 30 kW for SXG-65x30, and reaches up to 45 kW for the high-output SXG-90x45 model.
What production speeds can be expected?
Production speeds vary depending on the model and the specific application. The SXG-45x25 model operates at 5-30 m/min, while the larger SXG-90x45 model can reach speeds up to 8-120 m/min.
What do the screw diameter specifications indicate?
The screw diameter specification (e.g., 45+25) represents the primary and auxiliary extruder combination configurations, matching different production output requirements and material blending requirements.
